Default Model 59 Slide Stop Issues

Hi. I am new to this forum. I have a Model 59 that throws the slide stop out of the gun during rapid fire. My ginsmith advised me to replace the recoil spring. I found this strange but i did so. It helped for a while but the issue has re-surfaced. The s/n is A2466XX. Can anyone possible provide any answers? Thank you! Tylerboy. (tomfarina@msn.com)

PS-Can anyone advise the date or year of manufacture?

Last edited by Tylerboy; 01-08-2017 at 11:35 AM. Reason: Additional info requested.
Reply With Quote
  #2
Old 01-08-2017, 11:42 AM
SMSgt SMSgt is offline
Member
Model 59 Slide Stop Issues Model 59 Slide Stop Issues Model 59 Slide Stop Issues Model 59 Slide Stop Issues Model 59 Slide Stop Issues
Join Date: Jul 2010
Location: Florida
Posts: 2,718
Likes: 639
Liked 1,637 Times in 821 Posts
Default

Ask a different gunsmith...
Reply With Quote
  #3
Old 01-08-2017, 12:40 PM
Engine49guy's Avatar
Engine49guy Engine49guy is offline
SWCA Member
Model 59 Slide Stop Issues Model 59 Slide Stop Issues Model 59 Slide Stop Issues Model 59 Slide Stop Issues Model 59 Slide Stop Issues
Join Date: May 2009
Location: South Florida
Posts: 6,393
Likes: 1,253
Liked 5,760 Times in 1,981 Posts
Default

IIRC the slide stop is retained by the spring loaded plunger in the rear end of the guide rod that engages a detent on the slide stop cross pin,

The detent is underneath and cannot be seen in this pic
Check the spring loaded pin in the slide stop is functioning as well.

Check the spring loaded pins are not sticking in both the guide rod and slide stop.

The slide stop pin should only be able to pass through the slide when the notch is aligned with the pin hole like this:


PS if you look closely at the above pic you can see the spring loaded plunger in the bottom of the hole

Last edited by Engine49guy; 01-08-2017 at 12:46 PM.
Reply With Quote
The Following 4 Users Like Post:
  #4
Old 01-08-2017, 02:15 PM
Tylerboy Tylerboy is offline
Member
Model 59 Slide Stop Issues Model 59 Slide Stop Issues Model 59 Slide Stop Issues Model 59 Slide Stop Issues Model 59 Slide Stop Issues
Join Date: Jan 2017
Posts: 5
Likes: 0
Liked 1 Time in 1 Post
Default You found my problem!!

Engine49guy, THANK YOU very much for your time and effort with your reply including the photos!! The problem with my gun was the plunger at the chamber end of the guide rod. The spring is very weak and does not fully extend the plunger. I have just ordered a new guide rod assembly from Gun Parts Corp at $21.00 delivered. I am confident that it will solve my problem. Thanks again and have a great day! Tylerboy.
Reply With Quote
The Following User Likes This Post:
  #5
Old 01-08-2017, 04:09 PM
Alk8944's Avatar
Alk8944 Alk8944 is offline
Member
Model 59 Slide Stop Issues Model 59 Slide Stop Issues Model 59 Slide Stop Issues Model 59 Slide Stop Issues Model 59 Slide Stop Issues
Join Date: Jan 2007
Location: Sandy Utah
Posts: 5,799
Likes: 511
Liked 3,179 Times in 1,536 Posts
Default

As Engine49guy pointed out, the slide stop should only come out when the stop notch in the slide is aligned with the slide stop pin. This causes me to believe that the slide stop is likely damaged too, you should probably order one of them too!
__________________
Gunsmithing S&W since 1961
Reply With Quote
The Following User Likes This Post:
  #6
Old 01-08-2017, 05:11 PM
Tylerboy Tylerboy is offline
Member
Model 59 Slide Stop Issues Model 59 Slide Stop Issues Model 59 Slide Stop Issues Model 59 Slide Stop Issues Model 59 Slide Stop Issues
Join Date: Jan 2017
Posts: 5
Likes: 0
Liked 1 Time in 1 Post
Default

Thank you for the additional tip! I will do so. Regards, Tylerboy.
Reply With Quote
  #7
Old 01-10-2017, 08:47 PM
Engine49guy's Avatar
Engine49guy Engine49guy is offline
SWCA Member
Model 59 Slide Stop Issues Model 59 Slide Stop Issues Model 59 Slide Stop Issues Model 59 Slide Stop Issues Model 59 Slide Stop Issues
Join Date: May 2009
Location: South Florida
Posts: 6,393
Likes: 1,253
Liked 5,760 Times in 1,981 Posts
Default

Glad that it helped, Also glad you understood what I was driving at since I didnt point out that the spring I was referring to is replaceable and pinned inside the guide rod behind the plunger.

You can drive the retaining pin out of the guide rod and replace the plunger spring keeping that assembly as a spare. I have purchased replacement springs online from a company called WOLFF springs with very good luck.

Last edited by Engine49guy; 01-10-2017 at 08:48 PM.
Reply With Quote
  #8
Old 01-11-2017, 06:44 AM
Tylerboy Tylerboy is offline
Member
Model 59 Slide Stop Issues Model 59 Slide Stop Issues Model 59 Slide Stop Issues Model 59 Slide Stop Issues Model 59 Slide Stop Issues
Join Date: Jan 2017
Posts: 5
Likes: 0
Liked 1 Time in 1 Post
Default

Thanks again for another great idea. I will certainly do so.
