Model 19-2 vs 19-3

Joined
Oct 9, 2014
Messages
174
Reaction score
52
Location
Northern California
I have a dash 2 and a dash 3, both in 6". The dash 3 has a patridge front sight while the dash 2 has a rectangular front sight.
What other changes are there between the two and which is more desirable? Both are great shooters.

Register to hide this ad
Can you expand on the differences between your front sights?

To me, Patridge and rectangular would both be apt descriptions for the exact same sight profile.

That’s what I was thinking, too.

My 19-4 has a patridge sight:


Attachments

  • CE76B8A0-C290-4432-92D1-DEA6F8E99E54.jpg
    22.5 KB · Views: 90
What other changes are there between the two and which is more desirable? Both are great shooters.

No significant engineering changes between the M19-2 and -3. The dash 2 still has the diamond stocks, (they ended on all guns ca. 1968). The rear sight leaf screw was moved on the -3, and the later half of dash-3 production have the gas ring as part of the yoke, it was moved there from the cylinder, without an engineering change; it was moved back to the cylinder when the dash-4 was released.
Front sights were an option and both the -2 and -3 could have either the Bauman ramp or the Patridge, but usually the Patridge is only seen on the 6" barrels.

Either dash number is a desirable gun, IMO older is better as a collectible. I have a dash-3 from 1974.

Sights were optional - Patridge or Baughman. This has nothing to do with the -2 to -3 change.

The real difference between the two is the -2 has the rear sight leaf screw located directly above the barrel/cylinder gap. On the -3 it was moved forward, away from the gap.

Just me, but as I put more rounds down range and get older, I've started preferring guns with certain attributes over whether or not one dash is better than another or if it's P&R or has a target trigger and hammer.

Mind you this only goes so far, as I still don't own one with the ____ lock.

I have two Model 19s. A -4 and a -5. The dash 4 is P&R but has a serrated trigger. The dash 5 is not P&R, but has a smooth trigger. Both shoot well, but I like shooting the dash 5 much better because of that one thing. Give me a smooth or better yet, a smooth wide trigger face any day over a serrated trigger. Oh, and I shoot DAO all the time, so trigger feel is key.

I found this about the Model 19............

“pre”...............(1955) Thanks to S&W and Bill Jordan, introduced at K260001
19..................(1957) Stamping of model number
19-1...............(1959) Change extractor rod, right to left hand thread
19-2...............(1961) Delete trigger guard screw, change cylinder stop
.....................(1963) 50 made with 2-1/2” barrel; K544672-K544721
.....................(1966) 2-1/2” barrel introduced as standard
19-3...............(1967) Relocate rear sight leaf screw
66..................(1970) Introduced at K949100
19-4 (66-1)......(1977) Move gas ring from yoke to cylinder
19-5 (66-2)......(1982) Eliminate cylinder counterbore and pinned barrel
66-3...............(1986) New yoke screw, floating hand, and hammer nose bushing
19-6...............(1988) New yoke screw, floating hand, and hammer nose bushing
19-7 (66-4)......(1994) New rear leaf sight, drill and tap frame, change extractor, and Uncle Mike’s synthetic grips.
.....................(1995) Delete square butt
.....................(1997) Change to MIM thumbpiece and trigger
19-8 (66-5).....(1998) Sep – Change to MIM hammer and floating firing pin
.....................(1999) Discontinue 2-1/2” barrel
.....................(1999) Nov – Model 19 discontinued

At least on the 4inch guns, aren't the front sights on the -2's a separate addition while the -3's are integral to the barrel?

-2







-3
