Time For New Revolver Design?

Would love to see the Dan Wesson style come back.
Having different barrels on the same frame and interchangeable grips would fit right in with the current 'Lego' semiauto offerings.

I first saw a Rhino on the SCi-Fi show "The Expanse". The detective on Ceres carried one. Made sense it was a revolver, throws no brass into the air, recoils straight back, allowing the shooter to recover and shoot again. In low gravity, it makes sense. Space Force handgun?

I can barely keep up with my eyes as Jerry shoots 6,reloads and shoots 6 on target, in 2.99 seconds! Truly amazing.

About the only modern "new think" revolver I know of is the Chiappa Rhino.

Not modern.......They just put the barrel on the bottom.......With a revolving cylinder the barrel could be placed anywhere on the frame.

Quick question for you Revolver fans. If Smith & Wesson were to develop a NEW Revolver design, what do you think it would look like? IMHO, I think it should be an all steel "break top" version capable of firing in Single Action as well as Double Action mode. This will be advantageous to the shooter/owner as the design will allow him or her to eject empty shells quickly as well as load the Revolver quickly with Safariland & SKS speed loaders. Which S&W frames and which calibers should be made with this "new" Revolver design?

Here ya go!

All steel, DA/SA, break top, .44 caliber!


Attachments

  • IMG_1928.jpg
    166.4 KB · Views: 14
  • IMG_1929.jpg
    143.5 KB · Views: 10
Revolver technology has been well explored and taken about as far as it can go.

I'm not implying that there's no place for revolvers in modern times, but that the technology has been fully developed.

Don't forget the Mateba!

I'd be happy with refinements in QA/QC and a 9mm revolver with a 9mm length cylinder vs a .38/357 cylinder modified for 9mm. It would be shorter, resulting in a more compact revolver.

Last edited:
New Old design

Mr Emilio Ghisoni changed the revolver concept, and, remember, the Rhino was born from his project. The Mateba 6Unica! Alas it is too expensive to produce, and it still remains a style exercise, anyway. I have it, I live 10 miles from the original (and disappeared) factory, and I can guarantee it is a jewel.



Attachments

  • IMG_0956.jpg
    214.3 KB · Views: 1
By “aren’t as good as a Smith”, please elaborate. All S&W revolvers have a better single action trigger than the new Pythons and Anacondas. I’ll agree to that all day long.

My gunsmith who Ransome rests all sorts of handguns says the new Colts are across the board more accurate that Smiths. He used to prefer Smiths. I seriously doubt anyone could realistically wear out either an L frame nor a new Python. So I don’t see the superiority there either. Fit and finish, any of my 5 Colts are built nicer than any of my Smiths. The Pythons come with a grip that at least looks like wood. When I stopped buying Smiths years ago, they came with rubber grips. No hilary hole on a Colt. Rear sight that comes on a Colt doesn’t need anything but a droplet of loc-tite.

Quick question for you Revolver fans. If Smith & Wesson were to develop a NEW Revolver design, what do you think it would look like? IMHO, I think it should be an all steel "break top" version capable of firing in Single Action as well as Double Action mode. This will be advantageous to the shooter/owner as the design will allow him or her to eject empty shells quickly as well as load the Revolver quickly with Safariland & SKS speed loaders. Which S&W frames and which calibers should be made with this "new" Revolver design?

The evolution of the revolver is over 500 years old and each new generation has been better than the one before it, but in the last 75-80 years the improvements have been incremental and slower to arrive. It's about reached its ultimate level and trying to reinvent the wheel (gun) like Ghisoni and Chiappa has tried to do has not been very popular or improved a revolver's performance. Ammunition has been the bigger improvement in performance. "Inventing" a new top break is a step backwards and doesn't make the gun any easier to load or unload than the swing-out cylinder.

By “aren’t as good as a Smith”, please elaborate. All S&W revolvers have a better single action trigger than the new Pythons and Anacondas. I’ll agree to that all day long.

My gunsmith who Ransome rests all sorts of handguns says the new Colts are across the board more accurate that Smiths. He used to prefer Smiths. I seriously doubt anyone could realistically wear out either an L frame nor a new Python. So I don’t see the superiority there either. Fit and finish, any of my 5 Colts are built nicer than any of my Smiths. The Pythons come with a grip that at least looks like wood. When I stopped buying Smiths years ago, they came with rubber grips. No hilary hole on a Colt. Rear sight that comes on a Colt doesn’t need anything but a droplet of loc-tite.

The main feature of a double action revolver should be a really good double action trigger pull. Nobody has that out of the box. Smith & Wesson K, L, and N frame guns have the most potential for DA tuning. This is the primary reason Smith is better. ANY gun can have a good single action trigger, that doesn't take much to do.

The Pythons will shoot better groups at 25 yards and beyond with light target loads because of their 1 in 14 twist rate. The Smith will catch up to them with +P or magnum loads with their 1 in 18-3/4 twist rate. The light target loads are not spinning fast enough to remain stabilized at the longer distances in a Smith. A Smith with a well made 1 in 10 twist custom barrel will shoot better groups than a Python.

The Python has always been the best looking revolver ever made. Good looks don't win matches, though. However, most people don't compete, so they have a different set of values.

Those in search of a "really good double action trigger pull" need look no further than the Miculek Spring Kit. It's main claim to fame is the trigger pull weight is whatever you want it to be--although he cautions against going below 7 pounds lest it won't go bang.

The kit comes with the expected two springs, and the instructions. Now if you're like me, and think you have no need whatsoever for instructions on how to replace two springs in a S&W revolver, think again!!

NOTHING would move when I finished the first time around--locked up tighter than Dick's hat band!!

OH, okay---maybe I should have a look at those instructions. It was a worthwhile look. Everything worked as intended the second time around---and it was slicker than greased Owl doo-doo on a brass door knob!!

Ralph Tremaine

Last edited:
  • Like
Reactions: Dio
I bought my 6" Ruger Security Six Stainless used in 1976, had too heavy a trigger pull, a Bullseye or Trapper spring set solved that while retaining 100% reliability.
There was the High Standard Crusader revolver which never went into production, those who handled one said it had an excellent action.
